氣力輸送系統：高效物料輸送的關鍵力量

Pneumatic conveying system: the key force for efficient material conveying

在現代工業生產中，物料的輸送是一個至關重要的環節。從化工原料到食品顆粒，從建筑粉料到制藥成分，各類物料需要在不同的生產環節之間高效流轉。氣力輸送系統作為一種利用氣流能量在密閉管道內輸送顆粒狀物料的技術，憑借其獨特的優勢，在眾多行業中得到了廣泛應用。

In modern industrial production, material transportation is a crucial link. From chemical raw materials to food granules, from building powders to pharmaceutical ingredients, various materials need to be efficiently circulated between different production processes. As a technology that utilizes airflow energy to transport granular materials in closed pipelines, pneumatic conveying systems have been widely used in many industries due to their unique advantages.

一、工作原理：氣流帶動物料的神奇之旅

1、 Working principle: The magical journey of materials driven by airflow

氣力輸送系統的核心原理是借助氣流的動能來推動物料前進。當具有一定速度的氣流在管道中流動時，與物料顆粒充分接觸。這些物料顆粒受到氣流的拖曳力、浮力等作用，懸浮于氣流之中，隨著氣流的方向在管道內移動，從而實現從一處到另一處的輸送。

The core principle of pneumatic conveying system is to use the kinetic energy of airflow to push materials forward. When an airflow with a certain velocity flows in a pipeline, it comes into full contact with the material particles. These material particles are suspended in the airflow due to drag, buoyancy, and other effects, and move within the pipeline in the direction of the airflow, thereby achieving transportation from one place to another.

在水平管道輸送時，氣速需保持在一定水平，使顆粒均勻分散懸浮于氣流，防止顆粒在管壁下部沉積。一旦氣速低于臨界值，即沉積速度，顆粒就會開始沉積，影響輸送效率和管道暢通。而在垂直管道向上輸送時，隨著氣速降低，固體含量會增高，當氣速降至噎塞速度時，顆粒會匯合成柱塞狀，出現騰涌現象，壓力急劇升高，導致輸送困難 。

When transporting in a horizontal pipeline, the gas velocity should be maintained at a certain level to evenly disperse and suspend particles in the airflow, preventing particles from depositing at the lower part of the pipe wall. Once the gas velocity falls below the critical value, which is the sedimentation rate, particles will begin to deposit, affecting transportation efficiency and pipeline smoothness. When transported upwards in a vertical pipeline, as the gas velocity decreases, the solid content will increase. When the gas velocity drops to the choking velocity, the particles will merge into a plunger shape, causing a surge phenomenon and a sharp increase in pressure, leading to difficulties in transportation.

二、系統類型：多樣選擇滿足不同需求

2、 System type: diverse choices to meet different needs

稀相輸送：固體含量通常低于 1 - 10kg/m? ，操作氣速較高，大約在 18 - 30m/s。這種輸送方式適用于短距離輸送，一般輸送距離在 300m 以內。其特點是輸送速度快，設備簡單，投資成本相對較低。例如在一些食品加工廠，輸送面粉、糖粉等物料時，稀相輸送能夠快速將物料輸送至各個加工環節，滿足生產的及時性需求。

Dilute phase transportation: Solid content is usually below 1-10kg/m, The operating speed is relatively high, about 18-30m/s. This conveying method is suitable for short distance conveying, generally within a conveying distance of 300m. Its characteristics are fast conveying speed, simple equipment, and relatively low investment cost. For example, in some food processing plants, when conveying materials such as flour and sugar powder, dilute phase conveying can quickly transport the materials to various processing stages, meeting the timeliness requirements of production.

密相輸送：固體含量在 10 - 30kg/m? ，或固氣比大于 25 。操作氣速較低，通過較高的氣壓壓送物料。密相輸送適用于較遠距離輸送，可達 500m 以上 。像一些化工企業輸送塑料顆粒、化工原料粉末等，由于輸送距離較遠，采用密相輸送可以有效減少能量損耗，提高輸送效率。不過，密相輸送設備閥門較多，氣動、電動設備也多，輸送壓力高，對管道的耐磨性要求也更高。

Dense phase transportation: solid content between 10-30kg/m, Or the solid to gas ratio is greater than 25. The operating gas speed is low, and the material is pressurized with higher air pressure. Dense phase transportation is suitable for long-distance transportation, up to 500m or more. For some chemical enterprises that transport plastic particles, chemical raw material powders, etc., due to the long distance of transportation, using dense phase transportation can effectively reduce energy loss and improve transportation efficiency. However, dense phase conveying equipment has many valves, pneumatic and electric equipment, high conveying pressure, and higher requirements for pipeline wear resistance.

負壓輸送：管道內壓力低于大氣壓，物料自吸進料，但卸料需在負壓下進行，輸送距離相對較短。它的優點是設備投資和負荷較小，適合從多個供料點向一處集中輸送。比如在一些小型工廠，將車間內不同位置的物料集中輸送到一個處理點時，負壓輸送就較為適用。但其缺點是運行流速高，管道磨損嚴重，一旦出現磨損漏洞難以察覺。

Negative pressure conveying: The pressure inside the pipeline is lower than atmospheric pressure, and the material is sucked in by itself, but unloading needs to be carried out under negative pressure, and the conveying distance is relatively short. Its advantage is that it requires less equipment investment and load, making it suitable for centralized transportation from multiple feeding points to one location. For example, in some small factories, negative pressure conveying is more suitable for transporting materials from different locations in the workshop to a single processing point. But its disadvantage is that the operating flow rate is high, the pipeline is severely worn, and once a wear and tear leak occurs, it is difficult to detect.

三、獨特優勢：工業輸送的理想之選

3、 Unique advantage: the ideal choice for industrial conveying

高效連續輸送：氣力輸送系統能夠?qū)崿F(xiàn)連續不間斷的物料輸送，進料口可連續加料，大大提高了生產效率。與傳統的間歇式輸送方式相比，減少了輸送過程中的停頓時間，使生產流程更加順暢。

Efficient continuous conveying: The pneumatic conveying system can achieve continuous and uninterrupted material conveying, and the feeding port can continuously add materials, greatly improving production efficiency. Compared with traditional intermittent conveying methods, it reduces the downtime during the conveying process, making the production process smoother.

環保清潔：物料在密閉的管道內輸送，避免了粉塵飛揚和物料泄漏，減少了對環境的污染，同時也保障了操作人員的健康。對于一些對環境要求較高的行業，如食品、醫藥等，氣力輸送系統的這一優勢尤為突出。

Environmentally friendly and clean: Materials are transported in sealed pipelines, avoiding dust flying and material leakage, reducing environmental pollution, and also ensuring the health of operators. For industries with high environmental requirements, such as food and medicine, the advantage of pneumatic conveying systems is particularly prominent.

靈活布置：輸送管道可以根據工廠的布局和實際需求進行靈活設置，能夠適應復雜的空間環境，可水平、垂直或傾斜安裝，充分利用空間，減少占地面積。

Flexible arrangement: The conveying pipeline can be flexibly set according to the layout and actual needs of the factory, and can adapt to complex spatial environments. It can be installed horizontally, vertically, or diagonally, making full use of space and reducing footprint.

多功能集成：在輸送過程中，還可以同時進行物料的加熱、冷卻、干燥和氣流分級等物理操作，甚至某些化學反應，實現了多種功能的集成，提高了生產的綜合性和靈活性。

Multi functional integration: During the conveying process, physical operations such as heating, cooling, drying, and airflow classification of materials can be carried out simultaneously, and even certain chemical reactions can be carried out, achieving the integration of multiple functions and improving the comprehensiveness and flexibility of production.

四、廣泛應用：貫穿多個工業領域

4、 Widely used: spanning multiple industrial fields

化工行業：在化工生產中，大量的粉狀、顆粒狀原料和產品需要輸送。氣力輸送系統可用于輸送各種化工原料，如塑料顆粒、化肥、顏料等，確保生產過程中物料的穩定供應和高效流轉。

Chemical industry: In chemical production, a large amount of powdered and granular raw materials and products need to be transported. Pneumatic conveying systems can be used to transport various chemical raw materials, such as plastic pellets, fertilizers, pigments, etc., ensuring stable supply and efficient circulation of materials during the production process.

食品行業：從谷物、面粉到調味料、奶粉等各類食品原料和成品，氣力輸送系統都能發揮重要作用。它不僅保證了食品的衛生安全，還能實現精確的定量輸送，滿足食品生產的嚴格要求。

Food industry: Pneumatic conveying systems play an important role in various food raw materials and products, from grains and flour to seasonings, milk powder, and more. It not only ensures the hygiene and safety of food, but also achieves precise quantitative delivery, meeting the strict requirements of food production.

建筑材料行業：水泥、石灰、石膏粉等建筑材料的輸送是建筑行業生產的重要環節。氣力輸送系統能夠高效地將這些材料輸送到攪拌站、施工現場等，提高建筑施工的效率和質量。

Building materials industry: The transportation of building materials such as cement, lime, gypsum powder, etc. is an important link in the production of the building industry. The pneumatic conveying system can efficiently transport these materials to mixing plants, construction sites, etc., improving the efficiency and quality of construction.

醫藥行業：藥品的生產對環境和衛生要求極高，氣力輸送系統的密閉性和清潔性正好滿足了這一需求。它可以用于輸送藥品原料、中間體和成品，確保藥品在輸送過程中不受污染，保證藥品質量。

The pharmaceutical industry: The production of drugs requires extremely high environmental and hygiene requirements, and the airtightness and cleanliness of pneumatic conveying systems precisely meet this demand. It can be used to transport pharmaceutical raw materials, intermediates, and finished products, ensuring that drugs are not contaminated during transportation and guaranteeing drug quality.

五、維護要點：保障系統穩定運行

5、 Maintenance points: Ensure stable operation of the system

定期檢查管道：定期檢查輸送管道的磨損情況，尤其是彎頭、變徑等部位，這些地方由于氣流方向改變和流速變化，容易出現磨損。若發現管道磨損嚴重，應及時更換，防止物料泄漏和管道堵塞。

Regular pipeline inspection: Regularly inspect the wear of the conveying pipeline, especially the bends, reducers, and other parts, which are prone to wear due to changes in airflow direction and velocity. If severe pipeline wear is found, it should be replaced in a timely manner to prevent material leakage and pipeline blockage.

清潔過濾設備：氣力輸送系統中的過濾器、分離器等設備需要定期清潔，防止雜質和物料堆積，影響設備的正常運行和分離效果。同時，要檢查過濾元件的完整性，如有損壞及時更換。

Cleaning filtration equipment: Filters, separators, and other equipment in pneumatic conveying systems need to be regularly cleaned to prevent impurities and material accumulation, which can affect the normal operation and separation efficiency of the equipment. At the same time, it is necessary to check the integrity of the filter element and replace it promptly if it is damaged.

維護氣源設備：氣源設備如風機、空氣壓縮機等是氣力輸送系統的動力源，要定期檢查其運行狀態，包括壓力、溫度、振動等參數。及時更換易損件，如風機的皮帶、軸承，空氣壓縮機的密封件等，確保氣源穩定可靠。

Maintain air source equipment: Air source equipment such as fans, air compressors, etc. are the power sources of pneumatic conveying systems, and their operating status, including pressure, temperature, vibration, and other parameters, should be regularly checked. Timely replace vulnerable parts such as fan belts, bearings, and seals of air compressors to ensure stable and reliable air supply.

校準儀表儀器：系統中的壓力計、流量計、料位計等儀表儀器要定期校準，保證測量數據的準確性，以便操作人員及時掌握系統運行狀態，做出正確的調整和決策。

Calibration instruments: Pressure gauges, flow meters, level gauges, and other instruments in the system should be regularly calibrated to ensure the accuracy of measurement data, so that operators can timely grasp the operating status of the system and make correct adjustments and decisions.

氣力輸送系統以其高效、環保、靈活等優勢，成為現代工業生產中不可或缺的物料輸送方式。隨著技術的不斷發展和創新，氣力輸送系統將在更多領域得到應用，并不斷提升工業生產的效率和質量。

Pneumatic conveying systems have become an indispensable material conveying method in modern industrial production due to their advantages of high efficiency, environmental friendliness, and flexibility. With the continuous development and innovation of technology, pneumatic conveying systems will be applied in more fields and continuously improve the efficiency and quality of industrial production.
